力科AP015电流探头

发布时间:2017-01-11 信息有效期:30天 浏览:1412举报
力科AP015电流探头
  • 信息分类:生产测试 - 其它生产测试
  • 所在区域:广东省 - 深圳市
  • 有效日期:30天
  • 信息类型:产品信息
信息详情

The Teledyne LeCroy AP015 current probe can measure continuous current of 30Arms and peak pulses of up to 50A for durations up to 10 seconds. This probe also features an overheating protection circuit, which will display an on-screen warning to the user to prevent damage. A probe unlock detection feature is also built in to the AP015 to ensure accurate measurements.

AP015 Specifications/Features

  • Bandwidth (Probe Only): 50MHz
  • Coupling: AC, 1MΩ; DC, 1MΩ; GND
  • Risetime (typical): 7ns
  • Max Continuous Input Current: 30A
  • Max Peak Current (at pw): 50A for <10s
  • Sensitivity: 10mA/div to 50A/div
  • Amplitude Accuracy: ±1% of reading to 15A ±2% of reading to 30A
  • Maximum Circuit Voltage: 300V CAT I, 150V CAT II (Bare Conductor)
  • Interface: all ProBus Oscilloscopes
  • Cable Length: 2m (6.6ft)
  • Maximum Conductor Size: 5mm (0.2in)

寻找更多货源请登录:www.wl95.com或拨打电话0755-86016691。
